Alpha NXT29VM36s 29" 36mm leveä Hiilikuitukehä

Basic

• Name: Alpha 36S
•
• Code: NXT29VM36S
•
• Rim Type: Mountain Bike (Clincher, Hookless)
•
• Materials: Carbon Fiber (Toray T1100 + T1000)
•
• Edition: Supreme Edition
•
• ASTM Classification: Condition 3
•
• Warranty: 5 Years
•
• Release Time: February 2025

Specification

• Size: 29"
•
• BSD (Bead Seated Diameter): 622mm
•
• ERD (Effective Rim Diameter): 591mm
•
• Drillings: 24, 28
•
• External Width: 36mm
•
• Internal Width: 30mm
•
• Rim Height: 23mm
•
• Spoke Bed Offset: 3.0mm
•
• Rim Lip Thickness: 3.0mm
•
• Weight: 24Holes 242g | 28Holes 245g
•
• Valve Hole Diameter: 6.5mm (Presta)
•
• Spoke Holes Diameter: 4.5mm
•
• Spoke Holes Angle: Axial 6° | Radial 5°
•
• Assembly Hole Diameter: 7.5mm
•
• Drain Holes: Yes
•
• Tubeless Compatible: Yes
•
• Strength: 100J (24Holes) / 105J (28Holes) <Pointed Hammer, 25psi>

Recommendation

• Tire Size: 2.0" ~ 2.75"
•
• Tire Pressure: 18 ~ 32 psi
•
• Spoke Tension: 100 ~ 130kgf
•
• Max System Weight: 143Kg (24Holes) / 150Kg (28Holes)
•
• Ideal Valve Stem Length: 36mm

Appearance

• Carbon Weave: UD
•
• Finish: Free Coating

Application

• Cross Country (XCO, XCM, XCC), Marathon, Endurance Cross Country, Trail
• In the relentless pursuit of carbon fiber bicycle rim innovation, NEXTIE continues to break boundaries. For top-level mountain bike rims, the ultimate goals remain: lighter weight, greater strength, enhanced durability, and uncompromised riding comfort. The newly launched Supreme Edition Alpha 36S carbon mountain bike rim embodies our revolutionary solution. Specifically engineered for all forms of Cross Country riding, this rim features a 30mm internal width while maintaining a mere 240g weight, incorporating multiple core technological innovations

Best Feature

• 1. Molded Spoke Holes and Valve Stem Hole, Resulting in Rims that are Stronger and Lighter.
•
• 2. Material Breakthrough: Toray T1100 + T1000 Aerospace Grade Carbon Fiber.
•
• 3. 3rd-Generation Layer-up Structure.
•
• 4. Highly Strict Technical Test Methods — 100J for 24Holes & 105J for 28Holes.
•
• 5. 23mm Low-Profile Optimization for Riding Comfort and Tubeless-Ready.
